The DEYE SUN-5K–25K-SG01HP3-AU-AM2 HV Series is a premium range of three-phase high voltage hybrid inverters designed to maximize solar self-consumption, provide reliable backup power, and intelligently manage high-voltage battery storage.
Available in capacities from 5kW to 25kW, this versatile inverter series is ideal for residential homes, commercial buildings, and larger energy storage systems. Supporting on-grid, off-grid, and hybrid operation, the DEYE SG01HP3 series offers advanced battery management, high PV input capacity, AC coupling for retrofitting existing solar systems, and parallel operation for large-scale installations.
✔ Available in 5kW to 25kW output capacities
✔ Supports High Voltage Lithium Batteries (160V–700V)
✔ Hybrid, On-Grid and Off-Grid Operation
✔ AC Coupling for retrofitting existing solar systems
✔ Up to 16 inverters in parallel
✔ Supports multiple battery banks in parallel
✔ Up to 6 programmable battery charge/discharge time periods
✔ Supports charging batteries from a diesel generator
✔ 100% three-phase unbalanced output
✔ Dual MPPT design for maximum solar production
✔ High conversion efficiency of 97.6%
✔ IP65 weatherproof enclosure
✔ 10-Year Manufacturer's Warranty
Whether you're installing a new solar and battery system or upgrading an existing installation, the DEYE SG01HP3 series provides complete energy management for homes and businesses.
The inverter intelligently controls solar production, battery charging, grid import/export and backup power, helping reduce electricity costs while maintaining reliable power during grid outages.
The SG01HP3 series supports modern high-voltage lithium battery systems, delivering higher efficiency, lower cable losses and faster charging performance.
Battery Features
Designed to maximise energy harvest throughout the day.
Features include:
The DEYE SG01HP3 series supports a wide range of installation types.
Suitable for:
Take full control of your energy usage.
Features include:
During grid outages, the inverter seamlessly supplies critical loads using stored battery energy and available solar generation.
Benefits include:
The SG01HP3 series incorporates advanced protection features including:
Designed to perform reliably in demanding Australian environments.
| Feature | Specification |
|---|---|
| Models | 5kW, 6kW, 8kW, 10kW, 12kW, 15kW, 20kW, 25kW |
| Battery Type | High Voltage Lithium-Ion |
| Battery Voltage | 160V–700V |
| Max PV Voltage | 1000V |
| MPPT Trackers | 2 |
| Max Efficiency | 97.6% |
| MPPT Efficiency | 99.9% |
| Parallel Operation | Up to 16 Inverters |
| Communication | RS485, CAN |
| Protection Rating | IP65 |
| Cooling | Free Cooling / Smart Cooling |
| Installation | Wall Mounted |
| Warranty | 10 Years |
Installation must be completed by a licensed electrician and accredited solar installer in accordance with Australian Standards and local network requirements.
