The SAJ Caro Plus Series Home Wallbox is a premium residential EV charging solution designed for convenient, intelligent and solar-compatible home charging. The 11kW model delivers three-phase AC charging and comes standard with a generous 7-metre Type 2 charging cable, providing flexibility when positioning your vehicle in a garage, driveway or carport.
Designed to integrate with modern home energy systems, the Caro Plus supports PV charging, dynamic load balancing and intelligent energy management. When integrated with compatible SAJ energy management equipment, the charger can coordinate EV charging with solar PV and energy storage to make better use of available household energy.
11kW three-phase AC EV charging
400V AC, 16A three-phase operation
Type 2 charging connector
7m charging cable included as standard
Plug to Charge, RFID card or App start modes
Wall-mount installation or optional pole mounting
Solar PV compatible
Dynamic load balancing
Automatic phase switching
Monitoring and control via elekeeper
Adjustable charging current for optimised PV utilisation
IP65 weather-resistant enclosure for indoor or outdoor installation
IK10 impact protection
RCM certified
Operating temperature from -30Β°C to +50Β°C
The Caro Plus is particularly well suited to homes with rooftop solar. It supports zero-emission PV charging and can adjust charging current to optimise the use of available solar generation rather than unnecessarily drawing power from the grid.
With eManager integration, the Caro Plus can work alongside compatible PV and battery storage systems to optimise household energy usage. Dynamic load balancing also helps manage the charger's demand relative to other electrical loads in the home.
Choose the charging method that suits you:
Plug to Charge β Simply connect the vehicle to begin charging where configured.
RFID Card β Control charger access using an RFID card, useful where you want to prevent unauthorised charging.
App Control β Manage charging through the supported app ecosystem.
The charger also supports monitoring and control through SAJ's elekeeper platform.
The Caro Plus incorporates multiple electrical protection functions for safe residential EV charging, including:
30mA Type A + 6mA DC residual-current protection
Overcurrent protection
Residual current protection
Ground protection
Surge protection
Over-voltage and under-voltage protection
Over-frequency and under-frequency protection
Over-temperature protection
Relay-sticking protection
| Specification | SAJ Caro Plus 11kW |
|---|---|
| Model | AC011K-AE-55C3-ENP |
| Rated Power | 11kW |
| Power Supply | 3P + N + PE |
| Rated Voltage | 400V AC |
| Rated Current | 16A |
| Frequency | 50Hz |
| Connector | Type 2 |
| Cable Length | 7m |
| Start Modes | Plug to Charge / RFID Card / App |
| Installation | Wall Mount / Pole Mount Optional |
| RCD | 30mA Type A + 6mA DC |
| Ingress Protection | IP65 |
| Impact Protection | IK10 |
| Certification | RCM |
| Operating Temperature | -30Β°C to +50Β°C |
| Working Humidity | 5%β95% |
| Maximum Working Altitude | β€2,000m |
| Dimensions | 365 Γ 201 Γ 99.5mm |
| Net Weight | 3.2kg |
The datasheet identifies the 11kW version as model AC011K-AE-55C3-ENP with a three-phase 400V AC supply and 16A rated current.
For households with three-phase power, the SAJ Caro Plus 11kW provides a strong balance between charging speed and intelligent home-energy integration. Its solar compatibility, dynamic load management, app/RFID access, long 7m cable and IP65 construction make it suitable for both garage and outdoor residential installations.
Professional installation by a suitably qualified electrician is required.
