Take greater control of your home's energy with the SOFAR HYD Three Phase Hybrid Inverter. Designed to bring solar generation, battery storage and backup power together in one intelligent system, the HYD Series helps you use more of the electricity your solar panels generate and rely...
Vendor: SOFAR
Product Type: Inverter
$2,118.00
$2,300.00
$2,118.00
Please hurry! Only 5 left in stock
10 customers are viewing this product

Warranty and Returns

Description
Description
x

Take greater control of your home's energy with the SOFAR HYD Three Phase Hybrid Inverter. Designed to bring solar generation, battery storage and backup power together in one intelligent system, the HYD Series helps you use more of the electricity your solar panels generate and rely less on electricity from the grid.

Available in 5kW, 10kW and 15kW, the HYD Series is an excellent choice for three-phase homes, larger residential solar installations and properties with higher energy requirements.

Whether you're installing a battery now or building a solar system ready for energy storage, SOFAR gives you a flexible platform that can grow with your energy needs.

Store Your Solar and Use It Later

Solar panels often produce their most electricity during the middle of the day, when household consumption may be relatively low.

With a compatible battery connected to the SOFAR HYD, excess solar energy can be stored for use later — helping you make better use of your solar generation instead of relying as heavily on grid electricity after the sun goes down.

The HYD supports both lithium-ion and lead-acid battery systems, subject to SOFAR's compatible battery list.

Backup Power for Greater Energy Security

The HYD isn't just a solar inverter. It includes a dedicated backup output, allowing a properly designed system with compatible battery storage to supply selected loads when grid electricity is unavailable.

SOFAR specifies a 10ms default switching time, helping the system transition rapidly to backup operation.

For three-phase properties, another major advantage is the ability for the off-grid output to supply unbalanced loads, with three-phase separate output supported.

Flexible Solar Design with Up to 2 MPPTs

Different roof orientations shouldn't necessarily prevent you from getting the most from your available roof space.

The SOFAR HYD platform provides up to two MPPT trackers, giving installers greater flexibility when configuring solar arrays across different strings or roof orientations.

The inverter also provides a wide 180–960V MPPT operating range and up to 1000V maximum PV input voltage, providing substantial flexibility when designing larger PV systems.

Built for Larger Solar Systems

The HYD Series allows substantial solar arrays to be paired with the inverter.

Model Rated Output Recommended Maximum PV
HYD 5KTL-3PH 5kW 7.5kWp
HYD 10KTL-3PH 10kW 15kWp
HYD 15KTL-3PH 15kW 22.5kWp

These recommended maximum PV capacities are specified in the supplied SOFAR datasheet.

This means customers can choose an inverter that better matches their property, from a smaller three-phase residential installation through to a large home or higher-demand solar and battery system.

High Efficiency Means More From Your Solar

The HYD Series achieves up to 98.2% maximum inverter efficiency and up to 99.9% MPPT efficiency, helping minimise conversion losses and make effective use of available solar generation.

Ready for Expansion

Energy requirements can change over time.

SOFAR designed the HYD platform to support multiple parallel systems, providing greater flexibility when building larger energy-storage solutions. Selected models also support up to two battery inputs.

This makes the HYD particularly attractive for customers who want a system with room for future expansion rather than being locked into a basic solar-only inverter.

Smart Monitoring & Control

The HYD uses fully digital operation for greater control accuracy and provides multiple operating modes so the system can be configured around different energy requirements.

Communication options include CAN, RS485 and Wi-Fi, with optional 4G and LAN, while system information can be accessed through the LCD and app.

Designed for Australian Outdoor Installations

With an IP65-rated enclosure, wall-mounted design and operating temperature range from -30°C to +60°C, the HYD is designed for demanding installation environments. The inverter also incorporates a comprehensive range of electrical protection functions.

Key Benefits

  • Use more of the solar energy your system generates

  • Store excess daytime solar for use later with a compatible battery

  • Reduce reliance on grid electricity

  • Backup output for greater protection during grid outages

  • Three-phase unbalanced backup load support

  • Available in 5kW, 10kW and 15kW

  • Up to 22.5kWp recommended PV capacity with the 15kW model

  • Up to two MPPT trackers for flexible solar design

  • Up to two battery inputs on applicable models

  • Multiple intelligent operating modes

  • Multiple parallel systems supported

  • Up to 98.2% maximum efficiency

  • Up to 99.9% MPPT efficiency

  • Smart app and remote communications

  • IP65 protection

One Inverter for Solar, Battery & Backup

For customers looking beyond a conventional solar inverter, the SOFAR HYD Three Phase Hybrid Series provides a much more complete energy solution.

It gives you the ability to generate solar power today, add or operate compatible battery storage, intelligently manage how your energy is used and provide backup power when properly configured.
