The Solis S5-GR3P15K is a 15kW three-phase grid-tied inverter designed for larger residential and light commercial solar systems. With dual MPPTs, up to 20kW recommended PV power, 98.6% maximum efficiency and support for high-current modules, it offers a reliable and cost-effective solution for larger rooftop PV installations.
Large three-phase residential solar systems
Light commercial rooftop installations
Properties with two main PV orientations
Systems using higher-power solar modules
Export-controlled grid-connected systems
Sites requiring remote monitoring and control
2 independent MPPTs
Up to 20kW recommended PV power
Up to 32A input current per MPPT
Wide 160β1000V MPPT operating range
1100V maximum PV input voltage
Up to 98.6% maximum efficiency
Export power control support
SolisCloud remote monitoring and control
Automatic voltage stabilisation for weak-grid conditions
Integrated AFCI protection
IP66 protection
Wi-Fi communication dongle included
The S5-GR3P15K supports up to 20kW of recommended PV power, allowing a substantial solar array to be connected to its 15kW AC output.
Two MPPTs with four maximum PV string inputs provide flexibility for different roof orientations or separate array sections. The 160β1000V MPPT range and 1100V maximum input voltage also support a wide range of commercial and residential string configurations.
The inverter supports RS485 together with optional Wi-Fi and GPRS communication. SolisCloud provides remote system monitoring, upgrades and control, while export power control helps manage how much solar energy is sent back to the grid.
Automatic voltage stabilisation technology also supports more stable generation under weak-grid conditions.
| Specification | S5-GR3P15K |
|---|---|
| Rated AC Output | 15kW |
| Recommended Max. PV Power | 20kW |
| MPPTs / Max. Input Strings | 2 / 4 |
| Max. PV Input Current | 32A / 32A |
| Max. Short-Circuit Current | 40A / 40A |
| Max. PV Input Voltage | 1100V |
| MPPT Voltage Range | 160β1000V |
| Start-Up Voltage | 180V |
| Rated Grid Voltage | 230V / 400V |
| Rated Grid Frequency | 50Hz |
| Rated / Max. Output Current | 23.8A |
| Maximum Efficiency | 98.6% |
| EU Efficiency | 98.0% |
| Protection Rating | IP66 |
| Operating Temperature | -25Β°C to +60Β°C |
| Cooling | Intelligent redundant fan cooling |
| Dimensions | 310 Γ 563 Γ 219mm |
| Weight | 18.8kg |
| Display | LCD |
| Communication | RS485; optional Wi-Fi, GPRS |
| Country of Manufacture | China |
Β
Integrated protection includes DC reverse-polarity protection, short-circuit protection, output over-current protection, surge protection, grid monitoring, anti-islanding protection, temperature protection and an integrated DC switch.
AFCI protection is also supported, helping reduce the risk associated with DC arc faults. The IP66 enclosure is designed for demanding installation environments.
Complies with AS/NZS 4777.2:2020, IEC 62116, IEC 61727, IEC 60068, IEC 61683 and EN 50530, together with applicable IEC 62109-1/-2 and IEC 61000-6-1/-2/-3/-4 safety and EMC requirements.
The S5-GR3P15K combines strong PV capacity, high efficiency and straightforward three-phase grid connection in a compact inverter platform.
Its dual MPPT design, support for up to 20kW of PV, export control and SolisCloud monitoring make it a practical choice for larger homes and light commercial sites that want reliable solar generation without battery integration.
