The Sungrow SH-T range is a high-performance three phase hybrid inverter platform designed for larger residential properties and high-energy solar and battery installations.
Available in 15kW, 20kW and 25kW models, the range combines high-capacity solar input, three independent MPPTs, high-voltage battery compatibility, 50A fast battery charging and discharging, whole-home backup and 100% unbalanced output capability.
The SH15T, SH20T and SH25T share the same core hybrid platform, allowing customers to select the inverter size that best matches their solar array, battery system and household energy requirements.
| Model | Rated Output | Max PV Input | Battery Charge / Discharge Power | Peak Backup |
|---|---|---|---|---|
| SH15T | 15kW | 30kWp | 30kW / 15kW | 25.5kVA / 10 sec |
| SH20T | 20kW | 40kWp | 30kW / 20kW | 32kVA / 10 sec |
| SH25T | 25kW | 50kWp | 30kW / 25kW | 36.5kVA / 10 sec |
Â
The Sungrow SH-T range combines solar generation, battery storage and backup functionality within a single three-phase inverter.
Choose from:
SH15T – 15,000W rated AC output
SH20T – 20,000W rated AC output
SH25T – 25,000W rated AC output
All three models support three-phase operation at 220/380V, 230/400V or 240/415V.
The SH-T series provides substantial PV input capacity, making it suitable for large rooftop solar systems.
Maximum PV input varies by model:
SH15T – up to 30,000Wp
SH20T – up to 40,000Wp
SH25T – up to 50,000Wp
The range also supports a maximum PV input voltage of 1,000V, with an MPPT operating range of 150–950V and 180V startup voltage.
The SH15T, SH20T and SH25T feature three independent MPPT trackers, providing greater flexibility when designing large solar arrays across multiple roof orientations.
PV configuration includes:
3 independent MPPTs
5 PV strings in total
2 / 2 / 1 string configuration
Up to 80A total PV input current
32A / 32A / 16A MPPT input current
Up to 100A total DC short-circuit current
1,000V maximum PV voltage
150–950V MPPT operating range
Â
The SH-T range supports compatible high-voltage lithium-ion battery systems with a wide 100–700V battery operating range.
Battery performance includes:
100–700V battery voltage range
50A maximum charge current
50A maximum discharge current
Up to 30kW battery charging power
Maximum battery discharge power varies according to inverter size:
SH15T – up to 15kW
SH20T – up to 20kW
SH25T – up to 25kW
Actual maximum battery current depends on the connected battery.
The SH-T range incorporates a built-in 63A bypass for whole-home backup applications.
During a grid outage, the inverter can transition to backup operation in less than 10 milliseconds, helping maintain power to connected backup loads.
Backup capability scales with the selected inverter:
SH15T – 15kW rated backup output
SH20T – 20kW rated backup output
SH25T – 25kW rated backup output
Â
The SH-T range provides substantial short-duration peak power when sufficient PV and battery power are available.
SH15T – up to 25.5kVA for 10 seconds
SH20T – up to 32kVA for 10 seconds
SH25T – up to 36.5kVA for 10 seconds
This additional short-duration capacity can help accommodate equipment and appliances with high startup power requirements.
The SH-T range supports 100% unbalanced output in both on-grid and backup modes.
This is particularly useful for three-phase properties where household loads are not evenly distributed across each phase.
The SH-T platform delivers high conversion efficiency across all three models.
SH15T – 98.1% maximum / 97.6% European efficiency
SH20T – 98.2% maximum / 97.8% European efficiency
SH25T – 98.2% maximum / 97.8% European efficiency
Â
The SH-T range provides multiple communication interfaces for system monitoring, battery communication and energy management.
Connectivity includes:
WLAN
Ethernet
RS485
CAN
4 digital inputs
2 digital outputs
DRM0
Â
Sungrow integrates multiple protection functions into the SH-T platform.
These include:
Precise AFCI support
Grid monitoring
DC reverse-polarity protection
AC short-circuit protection
Leakage-current protection
Integrated solar DC switch
DC Type II surge protection
AC Type II surge protection
PID Zero
Battery reverse-polarity protection
Â
The SH15T, SH20T and SH25T feature an IP65 enclosure with C5 corrosion resistance, making the platform suitable for indoor or outdoor installation.
General specifications include:
IP65 / C5 protection
-25°C to +60°C operating temperature
0–100% allowable relative humidity
Maximum operating altitude of 2,000m
Wall-mounted installation
Plug & Play connections
LED display
AS/NZS 4777.2:2020 listed compliance
Â
Available in 15kW, 20kW and 25kW
Three phase hybrid solar and battery inverter
Up to 50kWp PV input depending on model
1,000V maximum PV input voltage
3 independent MPPTs
5 PV strings with 2 / 2 / 1 configuration
Up to 80A total PV input current
100–700V high-voltage battery range
50A fast battery charge and discharge current
Up to 30kW battery charging power
Up to 25kW battery discharge power depending on model
Built-in 63A whole-home backup bypass
Less than 10ms backup switching
Up to 36.5kVA peak backup output
100% unbalanced output support
Up to 98.2% maximum efficiency
Precise AFCI support
PID Zero
AC and DC Type II surge protection
WLAN and Ethernet connectivity
RS485 and CAN communication
IP65 / C5 protection
Plug & Play installation
AS/NZS 4777.2:2020 listed compliance
| Specification | SH15T | SH20T | SH25T |
|---|---|---|---|
| Phase | Three Phase | Three Phase | Three Phase |
| Rated AC Output | 15kW | 20kW | 25kW |
| Maximum PV Input | 30kWp | 40kWp | 50kWp |
| Maximum PV Voltage | 1,000V | 1,000V | 1,000V |
| MPPTs | 3 | 3 | 3 |
| PV Strings | 5 (2/2/1) | 5 (2/2/1) | 5 (2/2/1) |
| Battery Voltage | 100–700V | 100–700V | 100–700V |
| Max Battery Current | 50A / 50A | 50A / 50A | 50A / 50A |
| Max Battery Charge Power | 30kW | 30kW | 30kW |
| Max Battery Discharge Power | 15kW | 20kW | 25kW |
| Rated Off-Grid Output | 15kW | 20kW | 25kW |
| Peak Backup Output | 25.5kVA | 32kVA | 36.5kVA |
| Backup Peak Duration | 10 sec | 10 sec | 10 sec |
| Backup Switching | <10ms | <10ms | <10ms |
| Max Efficiency | 98.1% | 98.2% | 98.2% |
| Protection | IP65 / C5 | IP65 / C5 | IP65 / C5 |
| Dimensions | 620 × 480 × 245mm | 620 × 480 × 245mm | 620 × 480 × 245mm |
| Weight | 38kg | 40kg | 40kg |
The supplied datasheet shows the SH15T uses natural convection cooling with typical noise of 35dB(A), while the SH20T and SH25T use fan cooling with typical noise of 50dB(A).
The Sungrow SH15T, SH20T and SH25T provide a scalable three-phase hybrid solution for larger solar and battery installations.
With up to 50kW of PV input, three independent MPPTs, high-voltage battery support, 50A fast battery charging and discharging, 100% unbalanced output and whole-home backup, customers can select the inverter capacity that best matches their property while remaining on the same Sungrow hybrid platform.
